SICK GTB6-P4211 – Reliable, Advanced and High-Performance PNP | G6 Series
$ 44.00
About this item
The SICK GTB6-P4211 is a compact G6 Series sensor featuring background suppression, a PNP output, and a visible red Pin Point LED. Operating on 10–30V DC, it offers a specified sensing range of 35–140 mm, a maximum sensing range of up to 250 mm, and a switching frequency of 1,000 Hz.
Worldwide Shipping
Free shipping on orders over $500
Fast Shipping
1-3 dispatch on all the orders
Original Products
100% genuine industrial parts
30 Days Moneyback
Hassle-free returns & refunds
📝 Product Overview
The SICK GTB6-P4211 Photoelectric Sensor is a compact industrial photoelectric proximity sensor from the SICK G6 Series, designed for reliable object detection in automated machinery, manufacturing systems, and industrial control applications. Featuring background suppression technology, a visible red light source, and a compact housing, this sensor provides dependable detection performance in installations where space is limited and consistent object sensing is essential.
The SICK GTB6-P4211 is designed to detect objects using reflected light while suppressing the influence of objects or surfaces located behind the intended detection target. The SICK GTB6-P4211 has a maximum sensing range of up to 250 mm, with a specified sensing range of 35–140 mm. This operating range provides flexibility for applications that require detection of objects at different distances. The SICK GTB6-P4211 operates on a 10–30V DC supply voltage, supporting common low-voltage industrial control systems.
SICK GTB6-P4211 – Key Specifications
| Specification | Details |
|---|---|
| Model Number | GTB6-P4211 |
| Manufacturer | SICK |
| Part Number | 1052438 |
| Product Family | G6 Series |
| Product Type | Miniature Photoelectric Sensor |
| Detection Principle | Photoelectric proximity sensing |
| Detection Method | Background suppression |
| Maximum Sensing Range | 5–250 mm |
| Specified Sensing Range | 35–140 mm |
| Light Source | PinPoint LED |
| Light Type | Visible red light |
| Wavelength | 650 nm |
| Light Spot Size | Ø6 mm at 100 mm |
| Output Type | PNP |
| Switching Mode | Light/dark switching |
| Switching Mode Selection | Selectable |
| Maximum Output Current | ≤100 mA |
| Supply Voltage | 10–30V DC |
| Current Consumption | 30 mA |
| Response Time | <625 µs |
| Switching Frequency | 1,000 Hz |
| Connection | M8 male connector, 4-pin |
| Housing Shape | Rectangular |
| Housing Material | ABS/PC plastic |
| Front Screen Material | PMMA plastic |
| Dimensions (W × H × D) | 12 × 31.5 × 21 mm |
| Weight | Approx. 20 g |
| Enclosure Rating | IP67 |
| Protection Class | III |
| Operating Temperature | -25°C to +55°C |
| Adjustment | Mechanical spindle, 5 turns |
| Feature | Benefit |
|---|---|
| Background suppression | Helps distinguish target objects from backgrounds within the configured sensing range. |
| Extended maximum sensing range | Provides flexibility for different machine layouts and object-detection distances. |
| PNP digital output | Supports connection to compatible PLCs and industrial control inputs. |
| PinPoint LED | Provides a visible red light spot for easier alignment and commissioning. |
| 650 nm visible red light | Makes the sensing beam visible during setup. |
| 1,000 Hz switching frequency | Supports rapid object detection in suitable high-speed applications. |
| Response time below 625 µs | Enables fast detection of passing objects and components. |
| Selectable light/dark switching | Offers flexibility when configuring the sensor output. |
| M8 four-pin connector | Provides a compact connection for compatible sensor cables. |
| IP67 enclosure rating | Helps protect against dust and water exposure within the rating’s specified conditions. |
| Compact G6 Series housing | Fits installations where mounting space is limited. |
| Five-turn mechanical adjustment | Allows adjustment of the sensing distance for the intended application. |
| 10–30V DC supply | Supports integration into compatible industrial low-voltage systems. |
| Lightweight construction | Simplifies installation on suitable brackets and compact machine assemblies. |
| Application | Purpose |
|---|---|
| Industrial automation | Detects objects and components within automated processes. |
| Conveyor systems | Identifies products moving along conveyor belts. |
| Packaging machinery | Supports package detection and product-position monitoring. |
| Material handling | Detects components moving through handling equipment. |
| Assembly machines | Confirms the presence of parts during assembly operations. |
| Machine tools | Supports object detection in compatible machine-control systems. |
| Production lines | Monitors product movement and presence at selected stations. |
| Object presence detection | Identifies whether an object is present within the configured sensing range. |
| Position detection | Detects the presence of an object at a defined location. |
| Part counting | Provides switching signals for compatible counting systems. |
| Automated manufacturing | Supports non-contact detection in production processes. |
| PLC-controlled machinery | Supplies PNP switching signals to compatible PLC inputs. |
| Sorting systems | Helps detect items for suitable automated sorting arrangements. |
| Component feeding systems | Monitors the arrival or movement of parts in automated feeders. |
📦 What’s Included
- SICK GTB6-P4211 Photoelectric Sensor
- Connector cables, mounting brackets, and additional accessories are included only if specified in the seller’s offer.
